Mode

Single mode

Multimode

Polish

UPC

APC

PC

Insertion Loss

≤0.2dB

≤0.3dB

≤0.2dB

Return Loss

≥55dB

≥65dB

≥35dB

Interchangeability

≤0.2dB

Salt Spray

≤0.1dB

Repeatability

≤0.1dB (1000 times)

Vibration

≤0.2dB (550Hz    1.5mm)

Temperature

≤0.2dB (-40+85 sustain 100 hours)

Humidity

≤0.2dB    (+25+65 93 R.H.100 hours)

Apex Offset

0 μm ~ 50 μm

Radius of Curvature

7mm ~ 25mm

Standards-Compliant

ROHS,IEC and GR-326
